| รายการ (Spec) | ค่า (Value) |
| Enclosure mounting | Surface |
| Number of ways | RCCB 40A 30mA 4 + 4 way 8 + 4 way 8 + 8 way RCCB 63A 30mA 8 + 8way |
| Electrical connection | Copper busbar connection |
| [In] rated current | 100 A |
| [Ue] rated operational voltage | 240 V |
| Network frequency | 50/60 Hz |
| Short-circuit current | 10 kA |
| Options for Protection device type | QO miniature circuit breaker (MCB) – 2P in main incomer |
| QO miniature circuit breaker (MCB) – 1P in outgoer | |
| QO miniature circuit breaker (MCB) – 3P in outgoer | |
| QO residual current circuit breaker with overcurrent protection (RCBO) – 1P – 10 mA in outgoer | |
| QO residual current circuit breaker with overcurrent protection (RCBO) – 1P – 30 mA in outgoer | |
| QO residual current circuit breaker with overcurrent protection (RCBO) – 2P – 30 mA in secondary incomer | |
| Door type | Plain dolly – plastic |
| Door opening side | Upwards |
| Enclosure material | Phosphated cold rolled steel of 1.2 mm |
| Surface treatment | epoxy 60…150 µm |
| Colour | White (RAL 9003 |
| Standards | IEC 60439 |
| TIS 1436-2540 | |
| BS 5486-13 | |
| IP degree of protection | IP4X |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
